Introduction of Danbach towing AGV
DANBACH ROBOT

---

Product description:

Danbach towing AGV not only realizes the material and automatically delivers it to the designated location, but also enables the haul transport of the material through the trailing traction structure. Special requirements such as transport can be easily achieved by upgrading the traction structure. The towing AGV can carry up to 200kg and the traction can reach 500kg.

Product parameters:

Dimensions: L1790xW500xH460 (customizable)

Load: traction 500kg, load 200kg (customizable)

Turning radius: ≥400mm

Communication method: wifi LAN

Navigation type: magnetic strip navigation / laser navigation

Battery: lithium iron phosphate / lithium battery

Walking method: one-way walking

Operating speed: 0- 45m/min

Charging mode: manual / automatic

Parking accuracy: ± 25mm

Features of towing agv:

1. The towing operation mode can be realized;

2. Adopting secondary safety anti-collision measures with high safety;

3. The main body is made of high-strength sheet metal bending and welding, and the rigidity is excellent; the body is sprayed and processed, and the appearance is beautiful.
