Description of AGV requirements for ground driving
DANBACH ROBOT

---

First, the ground bearing capacity is 1.5T/m2 (in general), the special load bearing requirements are different, and the ground allowable pressure is 1.5MPa.

Second, the ground irregularity is less than 10mm in the range of 4000mm × 2000mm.

Third, the ground requirements can release the static electricity of the automatic guided vehicle, the insulation resistance is less than 108 (if it can not meet the requirements, you need to install anti-static board) AGV daily driving, the ground must be kept clean and dry. Any wrench, garbage, liquid, floor cleaner, or compound may damage the walking ability of the AGV. Electrostatic operation and excessive wheel friction can cause parts to be scrapped.

Fourth, the AGV trolley driving pavement should be based on concrete structure, but if the AGV trolley using magnetic navigation method must be clear, the distance between the uppermost steel and the ground should be 80mm. Underground metal objects are laid for certain types of AGV. Its guiding system may be disturbed by cables and metal objects. Metal pipes or metal objects under the automatic door will have an adverse effect on the magnetic navigation method. A small range of underground gold deposits should not affect the operation of the AGV.

Five, Expansion joints, settlement joints, anti-seismic joints and split joints have certain design requirements for these joints:

1. Try to avoid seams on the AGV path. It is necessary to consider the specific position I, the size of the seam and the planning of AGY8&&.

2. in the case of innocent special treatment. The AGV can pass seams up to 5 mm.

3. For joints with a width of 5-50mm, the upper 50mm can be filled with asphalt grease, the lower 100mm is embedded with foam plastic strip, or the M10 cement mortar is embedded, and the surface is padded with silicone paper as the isolation layer.

4. For seams with a width of 50-450mm, it can be treated with a metal cover.

5. For certain width of settlement joints, special methods or tools can be used for treatment, such as CoGri Joint Stabilisers (CJS). The ground bearing is different from the forklift. The AGV uses a fixed driving path, and the AGV replaces the pneumatic tire with a poly-ampere tire. Therefore, the AGV road surface must meet certain load-bearing requirements: the load per unit area of ​​the ground should be higher than the load per unit area within the projected area of ​​the AGV level.

Sixth, Other building requirements

Ground finishing is to make the AGV run smoothly and smoothly, and can finish the surface layer of the ground. This means laying a layer of cement, epoxy resin, P-type ceramic tile, wooden floor or other chemical fiber on the running surface of the AGV. Improve the flatness of the ground and reduce the impact of seams on the AGV.
